Before the first ride
bring the saddle back. Move the saddle within its
permitted displacement range only (marked on the
saddle stay).
Figure 36: Knee cap perpendicular line
6.2 Adjusting the handlebars
The handlebars must only be adjusted while the
bicycle is stationary.
Unfasten and adjust the designated screw
connections, and clamp them with the maximum
tightening torque for the clamping screws of the
handlebars.
Maximum tightening torque for the
clamping screws of the handlebars*
*if there is no other data on the component
5Nm - 7Nm
Table 11: Handlebars clamping screw maximum tightening torque
