Description
3.2 Handlebars
Figure 3: Detailed view of bicycle from rider position, example 1
Figure 4: Detailed view of bicycle from left, example 2
1 Rear brake lever
2 Headlight
3Bell
4 Front brake lever
5Shifter
6Shifter
7 Shift battery charging port
8 Long shifter
9 Brake lever
10 Short shifter
