Description
Dampers which dampen compressive deflection
movements, i.e. a compression load, are called
compression dampers or compression dashpots.
Dampers which dampen rebound deflection
movements, i.e. a rebound load, are called rebound
dampers or dashpots.
3.3.3 Suspension fork structure
Figure 8: Example showing Suntour fork: The stem and handlebars are
fastened to the fork shaft (1). The wheel is fastened to the quick
release axle (6). Other elements: The compression setting (2),
crown (3), Q-Loc (5), dust seal (6), fork end for quick release (7),
stanchion (8) and spring (9)
1
1
2
3
4
5
6
7
8
