Transportation, storage and assembly
Adjust the clamping with a half-open clamping lever
until the flange reaches the fork end.
Figure 29: Adjusting the clamping
Fully close the quick release. Check the quick
release to ensure it is firmly in place and adjust on
the flange if necessary.
The lever is secured.
Figure 30: Closing the quick release
