Description
3.2.1 Stem
The stem connects the fork to the handlebars. The
sitting position of the rider is changed and optimised
by changing the length and the angle of the stem.
Figure 5: Detailed view of the stem, example of stem which can be set
without tool
1 Stem clamping lever
2 Handlebars
3 Locking button
4Stem
