Before the first ride
Figure 38: Pulling locking lever upwards; by.schulz speedlifter used as an
example
6.2.2.1 Checking the clamping force of the quick releases
Open and close the quick releases on the stem or
the seat post.
The clamping force is sufficient if the clamping
lever can be moved easily from the open final
position into the middle and has to be pressed with
the fingers or base of the thumb from the middle
point onwards.
6.2.2.2 Adjusting the quick release clamping force
If the clamping lever on the handlebars cannot be
moved into its final position, screw out the knurled
nut.
Tighten the knurled nut on the seat post if the
clamping lever's clamping force is not sufficient.
If you are unable to set the clamping force, the
specialist dealer will need to check the quick release.
