Pegasus Piazza - Figure 10: Rim Brake Locking Lever, Closed (1) and Open (2); Figure 11: Bicycle Brake System with a Disc Brake, Example

MY19-P073_1.0_09.11.2018
32
Description
The hydraulic rim brake features a locking lever
Figure 10: Rim brake locking lever, closed (1) and open (2)
3.4.2 Disc brake
Alternative
Figure 11: Bicycle brake system with a disc brake, example
21
The rim brake locking lever is not marked with any
lettering. Only a specialist dealer may set the rim brake
locking lever.
1
2
3
4
5
