Maintenance
8.3.4.3 Cable-operated twist grip, dual-cable
Alternative
 For a smooth gear shift, set the adjusting sleeves
on the shifter housing.
 There is noticeable play of around 2–5 mm
(1/2 gear) when twisting the twist grip.
Figure 54: Twist grip with adjusting sleeves (1) and play of the gear shift (2)
1
2
