Pentax K20D User Manual

147
Using the Flash
5
Wireless Shooting
Using a Combination of the Built-in Flash and an External Flash
Unit
1 Remove the external flash unit for which the channel was set on the
camera, and place at the desired location.
2 Set the flash mode of the camera to r , and pop up the built-in flash.
3 Confirm that both flashes are fully charged and then take the picture.
Using a Combination of External Flash Units
1 Set the wireless mode of the external flash directly connected to the
camera to [MASTER] or [CONTROL].
2 On the wireless flash unit, set the wireless flash mode to [SLAVE] and
set the channel to the same channel as the camera. Then, place at the
desired location.
3 Confirm that both flashes are fully charged and then take the picture.
HSb (High-speed sync) is not available when the camera is set to discharge
the built-in flash.
MASTER
Discharges both the flash directly connected to the camera and
the wireless flash unit.
CONTROL
The flash directly connected to the camera is discharged as a
test flash only and does not discharge as main flash.
Shake Reduction is not available in Wireless mode.
Downloaded From camera-usermanual.com Pentax Manuals

Pentax K20D Specifications

General

Camera Type	Digital SLR
Sensor Type	CMOS
Sensor Size	23.4 x 15.6 mm
Resolution	14.6 MP
Continuous Shooting Speed	3 fps
Image Stabilization	Sensor-shift
Screen Size	2.7 inches
Screen Resolution	230, 000 dots
Storage Media	SD/SDHC
Dimensions	141.5 x 101 x 70 mm
Weather Sealing	Yes
Image Processor	PRIME (Pentax Real Image Engine)
Shutter Speed	30-1/4000 sec
Viewfinder	Optical (pentaprism)
Battery	Rechargeable Lithium-Ion battery
ISO Range	ISO 100 - 3200 (expandable to 6400)
