SMART I/O User’s Manual
March 12, 1996
©1996 PEP Modular Computers GmbH
Page 4 - 20
Chapter 4 Digital Modules
4.2.3 Front Panel Layout
4.2.4 Board Overview
Component Side
BU1 BU2
LED 0LED 7
LED Driver
Output
Transistors
Digital Output
Network
Optoisolation
Pin 1
Pin 15
Pin 2
Pin 16
Pin 1
Pin 15
Pin 2
Pin 16
ID Register
Yellow LEDs
User Descriptor
Fields
