SMART I/O User’s Manual
March 12, 1996
©1996 PEP Modular Computers GmbH
Page 6 - 6
Chapter 6 Communications Modules
6.1.3 Front Panel Layout
6.1.4 Board Overview
Component Side
SM-RS232
1 Serial
Interface
Green LED
Yellow LED
TxD
RxD
User Descriptor
Fields
216
BU1 BU2
LED 0
LED 1
EEPROM
Inverter
J1
Transceiver
115
216
115
