PEP Modular Computers Modular Computers RS485 - Isagraf Programming

SMART I/O User’s Manual
Page 4 - 68
Digital Modules
08 Jan. 98Manual ID 09901, Rev. Index 0500
Buffer Explanation:
Bit Value: 0 = No input or not connected
1 = Input Active
4.4.9ISaGRAF Programming
4.4.9.1 ISaGRAF Board Parameters
Information on board parameters may be found in the PEP on-
line help and ISaGRAF on-line help or user’s manual.
Figure 4-9: Typical Screen Section for the SM-
ACI1Module
D7 D0
Ch. 7Ch. 6Ch. 5Ch. 4Ch. 3Ch. 2Ch. 1Ch. 0
