Introduction
1
1.2 Ordering Information
Product Description Order Nr.
SMART-BASE
Micro PLC & real-time computer, 1 MByte EPROM, 512 kByte DRAM,
64kByte SRAM, OS-9 v3.0, ISaGRAF v3.0x, PROFIBUS v3.12, Layer
2 & 7, RTC, full modem RS232 (8-pin RJ45 connector), 190 mAh
battery, housing and terminal block for the 24V DC power supply
13843
SMART-BASE
As product 13843 but with additional 1 MByte Flash memory (TSOP) on
solder side
13844
SMART-EXT
Expansion module for the SMART-BASE supporting 2 SMART-Modules
Delivered without terminal blocks, SMART-Modules or blank panels
4228
SM-DIN1 SMART-Module with 8 optoisolated 24V DC digital inputs 4229
SM-DOUT1 SMART-Module with 8 optoisolated 24V DC/500mA digital outputs 4231
SM-DAD1 SMART-Module with 4 channel A/D (±10V), 2 channel D/A (±10V, 0..10V) 9868
SM-PT100 SMART-Module with 4 optoisolated 2, 3 or 4-wire PT100 inputs 12405
SM-THERM SMART-Module with 4 optoisolated thermocouple inputs 12426
SM-REL1 SMART-Module with 6 optoisolated normally open relay outputs 12238
SM-RS232 SMART-Module with RS232 (Rx & Tx) interface 12461
SM-SSI
SMART-Module with 1 SSI channel providing a 24V DC digital input and a
24V DC, 500mA digital output
12825
SM-ADC1 SMART-Module with 6 12-bit, ±10V optoisolated analog inputs 13380
SM-ADC1 SMART-Module with 6 12-bit, 0..20mA optoisolated analog inputs 13868
SM-DAC1 SMART-Module with 2 12-bit, ±10V optoisolated analog outputs 13379
SM-DAC1
SMART-Module with 2 12-bit, 0..20mA optoisolated analog outputs with
current sensing for broken sensor detection
14018
SM-DAC1 SMART-Module with 6 12-bit, ±10V optoisolated analog outputs 14019
SM-DAC1
SMART-Module with 6 12-bit, 0..20mA optoisolated analog outputs with
current sensing for broken sensor detection
14020
All SM-Modules are delivered without screw terminals.
