SMART I/O User’s Manual

Chapter 6 Communications Modules

6.2.7.2 CTRL1 Register

ENIO-P enable / disable (1 / 0) interrupt on parity error

ENI1-TC enable / disable (1 / 0) interrupt on transmission complete

ENI2-EOR enable / disable (1 / 0) interrupt on end-of-range switch 1 / 2

ENI3-MH enable / disable (1 / 0) interrupt on comparison match

DIR direction control (‘1’ activates the optocouplers)

SOT start transmission control (‘1’ = set; single-shot-set by lib.)

AR select automatic repeat mode (when set -> ‘1’)

RST set / clear (1 / 0) Reset output

6.2.7.3 CTRL2 Register

FDL0-4 number of data bits, excluding parity, minus 1

P enable / disable (1 / 0) use of parity (encoder dependent)

CF1-0 data transmission frequency:

0-0 62.5 kHz

1-0 125 kHz

0-1 250 kHz

1-1 500 kHz

6.2.7.4 CTRL3 Register

CM A logical ‘1’ clears the MATCH output and LED

DT data type (0:Gray, 1:Binary) according to encoder type

If ‘0’ is set, the result in the data register is binary.

PT parity type (0:Odd, 1:Even) according to encoder type.

CTRL1-7 CTRL1-6 CTRL1-5 CTRL1-4 CTRL1-3 CTRL1-2 CTRL1-1

RST AR SOT DIR EN13-MH EN12-EOR ENI1-TC

CTRL2-7 CTRL2-6 CTRL2-5 CTRL2-4 CTRL2-3 CTRL2-2 CTRL2-1

CF1 CF0 P FDL4 FDL3 FDL2 FDL1

CTRL3-7 CTRL3-6 CTRL3-5 CTRL3-4 CTRL3-3 CTRL3-2 CTRL3-1

unused unused unused unused unused PT DT
