Introduction
1.4.3 RJ45 Telephone Connector Installation
The RJ45 connector is fitted into the RS232 Telephone connector (BU1) on
the SMART-BASE. This is illustrated in the Figure below.
Figure 1.4.3.1 : RJ45 Telephone Connector Installation
1.4.4 Screw Terminal Block Installation
The Screw Terminal Blocks are easily fitted to the SMART-BASE or
SMART-EXT by pushing them onto the relevant Screw Terminal, as shown
in the figure below.
Figure 1.4.4.1 : Screw Terminal Block Installation
BU1
SCR2
RJ45 Connector
SMART-BASE
