SMART I/O User’s Manual
October 01, 1996
©1996 PEP Modular Computers GmbH
Page 5 - 90
Chapter 5 Analog Modules
5.4.3 Front Panel Layout
Red LEDs
User Descriptor
Fields
5.4.4 Board Overview
Component Side
2
16
BU1 BU2
LED 0
LED 1
Multiplexers
EEPROM
Optocouplers
DC/DC
ADC
J4
Optocouplers
Logic
1
15
2
16
1
15
Impedance
Converter
J2
