SMART I/O User’s Manual
March 12, 1996
©1996 PEP Modular Computers GmbH
Page 1 - 10
Introduction
Product Description Order Nr.
ISaGRAF-
ROM-START
ROM kit v3.x for SMART I/O enables the generation of custom
firmware EPROMs. Platform can be a PC or OS-9 development
system
13829
OS9TRG-RG-
SMART
Target CPU kit for SMART I/O (OS-9 v3.x/Ix.x disks) 11299
OS9DEVFT-
WIN-SMART
OS-9/68000 FasTrak for Windows development pack for SMART I/O.
Contains extended OS-9 v3.x/Ix.x, PEP utilities and I/O drivers with
necessary makefiles for complete application and EPROM
generation.
13887
OS9DEVFT-
UNIX-SMART
OS-9/68000 FasTrak for UNIX development pack for SMART I/O.
Contains extended OS-9 v3.x/Ix.x, PEP utilities and I/O drivers with
necessary makefiles for complete application and EPROM
generation.
13926
OS9-PFB-
SMART
OS-9 PROFIBUS starter kit II for 1 node. Includes license, disk and
manual
1662
OS9-PFB-
SMART(FT)
OS-9 PROFIBUS starter kit II for 1 node operating under FasTrak for
Windows. Includes license, disk and manual
12666
Cable
3 meters with 9-pin D-Sub (female) & RJ45 connectors for PC
operation
10890
Cable
3 meters with 25-pin D-Sub (male) & RJ45 connectors for modem
operation
10891
Screw Term. For the SMART-BASE timer I/O. Pack of 5, 2x3 array 10892
SCR-2*7. For the SMART-Modules. Pack of 5, 2x7 array 10893
Dummy FP For unused SMART-Module slots. Available in packs of 20 10894
Battery
3V, 190mAh lithium batery (button) BR2032 for use in the standard
temperature range (0°C to +70°C)
11281
Battery
3V, 850mAh lithium batery (cylinder) CR14250 for use in the
extendedtemperature range (-40°C to +85°C)
11282
1.3 Product Information
The SMART-BASE is a control module possessing an RS485 PROFIBUS
and serial RS232 interface as standard and provision for up to three SMART-
Modules. The modules currently available are discussed later. Normally, the
base unit is mounted on a DIN rail (see Weights & Measures section) which
in turn may be fixed in a cabinet. SMART-EXT units may be attached in a
similar manner.
