Introduction
1
The attachment of both units is achieved by sliding them over the DIN rail
with the clip assembly pulled out and then releasing it when correctly posi-
tioned.
The 24V supply source should possess the following characteristics:
Because of power limitations, it should be noted that although up to 11
SMART-Modules are possible in a complete configuration, attention should
be paid to the following tables that show the individual component power
requirements. The maximum of 6750mW should not be exceeded as damage
to the on-board DC-DC converter may result due to overheating or entering a
reset status due to the thermal cutoff protection switching mechanism.
Voltage Current
min max Continuous Peak
18V 36V 400mA 1.5A (2ms)
SM-BAS
E
Power Consumption
min max
CPU Core 1500mW 1700mW
Profibus 250mW 750mW
Module Power Consumption Module Power Consumption
min max min max
SM-DIN1 5mW 100mW SM-ADC1 350mW 450mW
SM-DOUT1 5mW 270mW SM-DAC1 5mW 400mW
SM-DAD1 350mW 450mW SM-DAC1 350mW 660mW
SM-PT100 400mW 500mW SM-SSI unknown unknown
SM-THERM 400mW 500mW
SM-RS232 23mW 75mW
SM-REL1 23mW 160mW
