PEP Modular Computers Modular Computers RS485 - Output Circuit

SMART I/O User’s Manual
©1996 PEP Modular Computers GmbHMarch 12, 1996 Page 4 - 23
4
Chapter 4 Digital Modules
Connection
Output Circuit
+Vcc (24V)
Gnd (0V)
OUT0
G03EXT
V01EXT
Typ: PNP
Load
BYM05-100
6.8 k
TIP125
Opto
TLP521
System Interface User Interface
+Vcc (24V)
Gnd (0V)
G03EXT G47EXT OUT7 OUT3 OUT6 OUT2 OUT5 OUT1 OUT4 OUT0
V01EXT
V45EXT
V23EXT V67EXT
Pin 1
Pin 2
Pin 13
Pin 14
Digital Actuators
Vcc Common (24V)
V01EXT
Channel 0
Channel 1
Vcc Common (24V)
V23EXT
Channel 2
Channel 3
G03EXT
OUT 0
OUT 1
OUT 2
OUT 3
