Chapter 4 Digital Modules
4.2.8.4 SMDOUT1Get
Syntax
error_code SMDOUT1Get(u_int8 PortNr, u_int8 *buffer);
Description
This function fetches the output status of the port PortNr and writes it to the
memory location pointed to by buffer. This buffer shows the status of all 8
outputs with bit 0 representing output 0 of the module.
Input
u_int8 PortNr SM-Port number to fetch data
u_int8 *buffer Pointer to a buffer where data is to be
stored.
Output
error_code SUCCESS
or standard OS-9 error code (refer to the OS-9
Technical Manual Error Codes Section).
Example
RetVal = SMDOUT1Get(0, buffer);
Buffer Explanation:
D7 D0
Ch.7 Ch.6 Ch.5 Ch.4 Ch.3 Ch.2 Ch.1 Ch.0
Bit Value : 0 = Output is ON
1 = Output is OFF
