64 . Frontier IR Single-range Spectrometers User's Guide
1. Lever out the fuse drawer so that it swings down over the power socket.
The fuse is in the right hand slot.
2. Remove the old fuse and discard it.
3. Fit the new fuse into the slot (Figure 33).
Figure 33 Fuse fitted; drawer open
4. Close the drawer.
The new fuse is now installed.
5. Reconnect the power cable and switch on the instrument.
