Peterbilt 220 - Table 3-1 Frame Height; Section3 Dimensions; Frame Height

To Next Page

To Previous Page

3-1

Section 3

Dimensions

Frame Height

Top of frame is the sum of the tires (SLR),the suspension, and the frame.

Table 3-1 Frame Height

Model Model 220 De-rated

Frame 10 ¼ inches 10 ¼ inches

Front Suspension

Rating 12K 10K

Unladen 8.1” 8.1”

Laden 5.9” 5.9”

Rear Suspension

HAS 210/230

Unladen 8.5” 8.5”

Laden 8.3” 8.3”

79KB 21,000#

Unladen 9.18” 9.18”

Laden 6.75” 6.75”

Tires (SLR) Tire GVWR

245/70R 19.5 G N/A 15.5” 26,720

265/70R 19.5 G N/A 15.9” 30,990

255/70R 22.5 H N/A 17.2” 31,300

275/70R 22.5 J 17.6” 17.6” 39,580

295/75R 22.5 G 18.8” 18.8” 35,050

11R 22.5 G 19.5” 19.5” 35,710
