Peterbilt 220 - Table 3-2 Turning Radius; Turning Radius

3-2
TURNING RADIUS
Approximate turning radius specifications for the Model 220 are listed (by wheelbase) in the following tables. Tables 3-2 Turning
Radius and 3-3 Cab Tilt Height information for chassis with standard components. Optional components may give different results.
Table 3-2 Turning Radius
Model
Rear
Axles
Wheelbase Range
Curb to Curb Est. Radius
Wall to Wall Radius Est.
Inch
mm
ft
m
ft
m
Model 220
Single
121
3073.4
17.5
5.3
23.5
7.2
142
3606.8
18.4
5.6
24.4
7.5
146
3708.4
19.40
5.9
25.40
7.7
156
35162.4
20.1
6.1
26.1
4.0
158
3962.4
20.50
6.2
26.50
8.1
164
4165.6
21.2
6.5
27.2
8.4
168
4267.2
21.7
6.6
27.7
8.5
170
4318
22.04
6.7
28.04
8.5
182
4622.8
23.36
7.1
29.36
8.9
194
4927.6
24.69
7.5
30.69
9.4
206
5232.4
26.01
7.9
32.01
9.8
218
5537.2
27.33
8.3
33.33
10.2
230
5842
29.13
8.9
35.13
10.7
242
6146.8
29.97
9.1
35.97
11.0
274
6959.6
33.5
13.1
39.35
15.5
Section 3
Dimensions
