Section 6

Frame Modifications

TORQUE REQUIREMENTS

Torque values apply to fasteners with clean threads, lightly lubricated, with hardened steel washers, and nylon-insert

nuts.

Table 6-1 Customary Grade 8 UNF or UNC

Fastener

Torque

Size

Lb-Ft

5/16

22-30

16-22

3/8

41-54

30-40

7/16

75-88

55-65

109-122

80-90

9/16

156-190

115-140

5/8

224-265

165-195

394-462

290-340

7/8

517-626

380-460

952-1129

800-830

1-1/8

1346-1591

990-1170

1-1/14

1877-2217

1380-1630

Table 6-2 U.S. Customary - Grade 8 Metric Class 10.9

Fastener

Torque

Size

Lb-Ft

9-15

7-11

23-31

17-23

M10

33-43

24-32

M12

75-101

55-75

M14

134-164

99-121

M16

163-217

120-160

M20

352-460

260-340
