Pfaff Creative Vision User Manual

10:2
23
19 20 21
22
8
17 18
15 16
910
13 14
11
6
1234
7
5
12
Files & Folders
Parts of the selection bar
1. Stitches
2. Fonts
3. Designs
4. Files & Folders
5. Quick help
Parts of Files & Folders
6. Load fi le
7. Close and return to previous view
8. Search path
9. Move up one folder level
10. List view
11. Selection area
12. Scroll bar
13. ”Personal fi les” folder
14. ”Personal fonts” folder
15. ”Personal designs” folder
16. External devices (only visible when a
device is connected)
17. Create new folder
18. Rename fi le or folder
19. Cut
20. Copy
21. Paste
22. Delete
23. File name of selected fi le
Files & Folders - overview
Files & Folders is used to organize, add, move,
remove and copy all your designs, fonts and stitch
fi les. Use either built-in memory or an external
device connected to your machine for storing.
While loading the fi les to the selection area a
default icon is shown in the meantime.
File formats
Your machine can load the following fi le formats:
• .SHV, .DHV, .VP3, .VIP, .HUS, .PEC, .PES,
.PCS, .XXX, .SEW, .JEF, .EXP, .10* and .DST
(embroidery fi les)
• .SPX (stitch fi les)
• .SFX (stitch font fi les)
• .VF3 (embroidery font fi les)
• .TXT and .HTM/HTML-fi les
Note: If the fi le type or fi le version is not supported by
your machine, or the fi le is damaged, it is shown in the
selection area as an unrecognized fi le.
Design fi le
Embroidery font fi le
Stitch fi le
Stitch font fi le
Text fi le
Sound fi le
Unrecognized fi le

Pfaff Creative Vision Specifications

General

Sewing Speed	1000 stitches per minute
Display	Color Touch Screen
USB Connectivity	Yes
Screen	Color Touch Screen
Needle Threader	Automatic
Bobbin Winding	Automatic
Automatic Thread Cutter	Yes
Embroidery Area	360mm x 200mm
Stitch Length	6mm
Stitch Width	9mm
