Introduction
Rear side
33. Handle
34. IDT
35. Embroidery unit connection socket
Top parts
36. Pre-tension device for threading and bobbin
winding
37. Bobbin winder thread guide
38. Thread guide
39. Bobbin thread guides
40. Bobbin winder lever
41. Bobbin spindle
42. Bobbin thread cutter
43. Auxiliary spool pin
44. Spool caps
45. Spool pin
46. Thread tension
47. Take-up lever
Accessory tray
The accessory trays feature special compartments
for presser feet and bobbins, plus space for needles
and other accessories. Store the accessories in the
tray so they are easily accessible.
48. Space for accessories
49. Removable tray for presser feet
50. Removable bobbin holder
Embroidery unit accessory tray
Accessory tray
