2:8
1
2
43
C
B
A
B
C
A
Preparations
Winding while embroidering or sewing
Swing the auxiliary spool pin up. Place an
appropriate spool cap, felt pad and thread spool on
the spool pin.
The needle thread (blue) is placed into the thread
guide (A) and underneath the bobbin winder
thread guide (B). Pull the bobbin thread (red)
counter-clockwise above the bobbin winder thread
guide (B) and through the bobbin thread guides
(C). Then follow step 4 and 5 on the previous page.
Inserting the bobbin
1. Remove the bobbin cover by sliding it towards
you.
2. Place the bobbin in the bobbin case with the
logotype facing up and the thread unreeling
from the left of the bobbin. The bobbin will
then rotate counter-clockwise when you pull
out the thread.
3. Place your nger on the bobbin to keep it from
turning as you pull the thread rmly to the
right and then to the left into the tension spring
(A) until it “clicks” into place.
4. Continue threading around (B) and to the right
of the thread cutter (C). Replace the cover. Pull
the thread to the left to cut.
