Pfaff Creative Vision User Manual

2:9
A
Preparations
IDT (Integrated dual feed)
For sewing any fabric precisely PFAFF® creative
vision™ sewing and embroidery machine provides
the ideal solution: the integrated dual feed, IDT
system. As on industrial machines, the IDT feeds
the fabric from the top and bottom at the same
time. The material is fed precisely. On light fabrics
such as silk or rayon the dual feed prevents
puckering of the seam. The even feeding action
also ensures perfect matching of checked and
striped fabrics. The IDT keeps all layers of quilt
projects aligned to prevent shifting of the top
layers.
Engaging the IDT
Important: For all work with the IDT, use presser
feet with the center back cut-out.
Raise the presser foot. Press the IDT down until it
engages.
Disengaging the IDT
Raise the presser foot. Hold the IDT with two
fi ngers at the ribbed ankle. Pull the IDT down, then
pull it away from you to release the IDT slowly
upward.
Electronic knee-lift
Your machine comes with an electronic knee-lift
for regulating the presser foot height.
Insert the knee-lift in the provided hole on the
machine. The fl at side must face upwards. Adjust
the rectangular bar on the knee-lift until it is
positioned at a comfortable height for you (A).
If you press the knee-lift to the right, the presser
foot will raise. You can now guide the fabric with
both hands.
To remove the knee-lift, just pull it straight out of
the hole.

Pfaff Creative Vision Specifications

General

Sewing Speed	1000 stitches per minute
Display	Color Touch Screen
USB Connectivity	Yes
Screen	Color Touch Screen
Needle Threader	Automatic
Bobbin Winding	Automatic
Automatic Thread Cutter	Yes
Embroidery Area	360mm x 200mm
Stitch Length	6mm
Stitch Width	9mm
