Phoenix Contact PSR-TRISAFE-S User Manual

SAFECONF configuration software
103503_en_03 PHOENIX CONTACT 4-23
Exiting the EASYSIM
simulation
To exit the EASYSIM simulation:
1. First exit simulation mode in the configuration software (deselect the "Simulate Safety
Controller" button).
2. Then select "Exit" in the EASYSIM context menu (in the Windows taskbar) or click on
"Exit" in the EASYSIM window.
Additional information
about operating EASYSIM
For additional information about the EASYSIM controller simulation, please refer to the
"EASYSIM controller simulation" section in the online help for the SAFECONF configuration
software:
–Operating EASYSIM
– Simulating time sequences in EASYSIM expert mode
– Status of the EASYSIM simulation
Exiting simulation mode is not the same as exiting the EASYSIM simulation.
Once the "Simulate Safety Controller" icon is selected again, the destination system is
reset in the configuration software, from the EASYSIM simulation to the real
PSR-TRISAFE-S safety module. This means that, essentially, the connection between
the configuration software and the simulation software is only interrupted. The EASYSIM
simulation application is not exited automatically (see below).
If EASYSIM is exited while the "Simulate Safety Controller" button is activated in
SAFECONF, EASYSIM restarts automatically after being exited.
