Pinnacle Operators Manual
Pickering Laboratories Inc.
Read this First!
Before attempting to install the Pinnacle PCX post-column derivatization instrument, it is vitally important that
you read this manual first, and attend to site, HPLC, and accessories requirements:
HPLC – Page 5
Gas Supply Requirements – Page 5
Reagent Reservoir bottles – Page 5
Computer – Page 5
Symbols and Warnings
Caution – this symbol indicates that caution must be used when dealing with this part.
Hot – this symbol is located on the Heated reactor, which can reach scalding temperatures.
Specifications
INSTRUMENT
Dimentions
21.50 H x 10.63 W x 18.25 D inches (54.0 x 26.7 x 46.4 cm), instrument only, doors closed
Weight
77lbs for Dual-pump systems
67lbs for Single-pump systems
Reagent Pumps
Max operating pressure 500 psi (35bar)
Flow rate range 50μl –1500μl/minute
Refill cycle 60 seconds
Heated Reactor
5°C above ambient to 130°C
Thermal Safety switch limits temperature to 150°C
Stability +/- 0.5°C
Accuracy +/- 1°C
