8.2
Appendices
Pinnacle Operators Manual
Pickering Laboratories Inc.
Installation/Operational Qualitication of the Pinnacle PCX
Installation Qualification Completed By: ___________________________ Date: _____________
Operational Qualification Completed By: __________________________ Date: _____________
1.0 PURPOSE:
To qualify the installation and operation of the Pinnacle PCX
2.0 REFERENCES:
2.1 Operators Manual for the Pinnacle PCX
2.2 Installation / Operational Qualification of the Pinnacle PCX Data Sheet. Section 8.3 of the Operators
Manual for the Pinnacle PCX.
3.0 EQUIPMENT: Date Initials
3.1 Installation / Operation Qualification
Coordinator: _________________________ ________ __________
3.2 Equipment:
Asset #: _________________________
Serial #: _________________________
Location: _________________________ ________ __________
4.0 GENERAL INSTALLATION QUALIFICATIONS: Date Initials
4.1 Pinnacle Site Requirements:
Space: 21.50 H x 10.63 W x 18.25 D inches (54.0 x 26.7 x 46.4 cm)
Electrical: 120 or 240 V
Weight: 26 lbs (11.6 kg) for Dual-pump systems
Gas: Nitrogen or Helium
4.2 Pinnacle Installation Qualification:
4.2.1 Follow Section 3 in the Operators Manual for the Pinnacle PCX for installation details of
the Pinnacle PCX.
4.2.2 Complete the Installation Qualification Check List in the Installation Operation / Qualification of
the Pinnacle PCX Data Sheet, Section 8.7 of the Operators Manual for the Pinnacle PCX.
5.0 OPERATION QUALIFICATION: Date Initials
5.1 Pump Flow Rate Accuracy
5.1.1 Turn on the Pinnacle PCX.
5.1.2 Fill the reagent bottle with Water and tightly close the cap.
5.1.3 Make sure the reagent caps are not vented to the atmosphere and that the lines to the pump are
open (parallel), and turn the gas toggle valve to “ON”.
