Pickering Laboratories Pinnacle PCX - Flow Diagram - Duplex

8.17
Appendices
Pinnacle Operators Manual
Pickering Laboratories Inc.
PUMP 1
VA LVE 2
PUMP 2
TRANSDUCER 2
FLUSH
R2
R1
FILTER
FILTER
COLUMN
HEATED
REACTOR
AMBIENT
REACTOR
TRANSDUCER 1
VA LVE 1
WASTE
FROM
HPLC
TO DETECTOR
1
6
5
2
3
4
1
6
5
2
3
4
Nut: 1452-0118
Ferrule: 1452-0117
1552-0017
1452-0184
1452-0093
1452-0185
1452-0189
1552-0017
1452-0184
1452-0189
1452-0093
1452-0185
3102-9040
1452-0041
1452-0183
Nut: 1452-0118
Ferrule: 1452-0117
1452-0040
Nut: 1452-0118
Ferrule: 1452-0117
3102-9040
Coupler: 3102-3064
2102-0463
Check V
alve: 3106-1007
Nut: 1452-0118
Ferrule: 1452-0117
Union: 3102-3063
Back Pressure
Regulator: 3102-9025
Nut: 1452-0113
Ferrule: 1452-0115
Nut: 1452-0114
Ferrule: 1452-0112
1452-0188
1100-2927
1452-0188
2102-0463
2103-0463
Nut: 1452-0180
Ferrule: 1452-0181
Nut: 1452-0116
Ferrule: 1452-0115
Nut: 1452-0116
Ferrule: 1452-0115
Nut: 1452-0118
Ferrule: 1452-0117
Nut: 3101-0011
Ferrule: 1452-0112
Nut: 1452-0226
Ferrule: 1452-0112
Nut: 1452-0113
Ferrule: 1452-0115
Nut: 1452-0113
Ferrule: 1452-0115
bold = kit
Flow Diagram – Duplex
