2.12
Section 2
Overview
Pinnacle Operators Manual
Pickering Laboratories Inc.
Relay Ports
The relays will be explained in the operations chapter under Site Requirements.
Ethernet Port
This port is used for connecting the Pinnacle PCX to a network.
POWER SWITCH AND MAIN FUSE
The power connector is a standard IEC 320 type connector. Use the appropriate power cord for your local wall
outlet and electrical code.
The 120V version comes with a standard North American cord set.
The 240V version comes with a cord set used in much of continental Europe.
Your local reseller may have provided the correct local cord set. If your local power outlets are different, you
will need to obtain the appropriate grounded cord set.
The main power switch is located in the power connector assembly.
The fuse holder is located in the power connector assembly. To change the fuse, first remove the power cord
from the connector. Carefully pry out the fuse clip with a small screwdriver. Replace with the specified-type
fuse: 2 ea, 5mm x 20 mm, 6 A, time lag.
Warning. Ensure that the power cord is disconnected before replacing a fuse. Use only the specified-type fuse.
Attention. Assurez vous que le cable secteur n’est pas connecté avant de changer un fusible.
Warnung. Sicherungen dürfen nur bei nicht angeschlossenem Netzkabel ersetzt oder gewechselt werden.
Cuidado. Asegúrese que el cable de red está desconectado antes de instalar o cambiar un fusible.
Attenzione. Assicuratevi che il cavo di alimentazione sia scollegato prima di installare o sostituire un fusible.
Waarschuwing. Zorg dat de voedingskabel losgekoppeld is, voordat een zekering wordt geplaatst of vervangen.
Avvertimento. Fare atenzione che la corda del voltaggio sia staccata prima di cambiare valvole. Usa solo
valvole di capacitá precisata dalla fattoria.
