3.7
Section 3
InstallatIon
Pinnacle Operators Manual
Pickering Laboratories Inc.
SECURITY LEVEL
Select who can access the Pinnacle PCX program. “Everyone” will allow access to many users while “Just me”
will only one user.
REGISTER
Complete the registration form and e-mail directly to support @pickeringlabs.com or print and fax to
(650) 968 – 0749.
OPTIONAL
Connecting the Pinnacle PCX to the network
It is at the user’s discretion if they would like their Pinnacle PCX placed on their company network. This will
involve working closely with the Company’s IT personnel, to determine proper address and their network
security procedures.
A network cable is provided with the Pinnacle PCX
Connector RJ45
Connection Speed 10/100-Base-T
Ethernet protocol TCP/IP
IP address User set or DHCP
DHCP IP address is assigned by a DHCP server. The network administrator must configure the DHCP server so
that the same address is reserved for and always given to Pinnacle PCX.
User set or Static IP address is set in the Pinnacle PCX. The network administrator must provide an address
specifically for Pinnacle PCX.
Note: We recommend connection to a Network Switch or Router, or direct connection to a dedicated Network
card in the PC.
Setting up or Changing User set (Static) IP address Follow the chart below:
Note: Use the MODE button to go through options and the SELECT button to select the option. Messages appear
at the bottom of the main LCD screen.
Turn Pinnacle PCX ON. While instrument is initializing press the STOP button and hold till the message reads:
BOOT: 1-04 CPLD: 2.5
DHCP IP: 192.168.111.111
To Next Page
