Pioneer PDP-5000EX

PDP-5000EX
173
5678
56
7
8
C
D
F
A
B
E
10
11
8
9
12
14
13
15
1
2
5
7
6
3
4
1 STANDBY/ON button
Press to put the unit in operation or standby mode .
2 SCREEN SIZE button
Press to select the screen size .
3 PC AUTO SET UP button
When using computer signal input, automatically sets the
"Position", "Clock" and "Phase" to optimum values .
4 INPUT 1 to 6 buttons
Press to select the input.
5 VOLUME (+/–) buttons
Use to adjust the volume .
6 MUTING button
Press to mute the volume.
7 RETURN button
Restores the previous menu screen.
8 AV SELECTION button
Use to select the AV function .
9 DISPLAY button
Press to view the unit's current input and setup mode.
10 SPLIT button
Press to switch to multi-screen display.
11 SUB INPUT button
During multi-screen display, use this button to change inputs to
subscreens .
12 SWAP button
During multi-screen display, use this button to switch between
main screen and subscreen .
13 HOME MENU button
Press to open and close the on-screen menu .
14 ADJUST (»/«/|/\) buttons
Use to navigate menu screens and to adjust various settings on
the unit.
15 ENTER button
Press to adjust or enter various settings on the unit .
• Remote control unit
