Pioneer PDP-5000EX Service Manual

PDP-5000EX
94
1234
1234
C
D
F
A
B
E
50FHD SCAN B
2 -1
1
1
1
4
4
Disconnect the six connectors.
Disconnect the one connectors.
Remove the five screws.
2
3
Unhook the three hooks.
Unhook the five hooks.
4
Remove the 50FHD SCAN B Assy.
5
5
2
4 4
3
3
50FHD SCAN B Assy
POWER SUPPLY Unit
2 -2
1
Disconnect the seven connectors.
Disconnect the one connectors.
Remove the four screws.
2
3
4
Remove the POWER SUPPLY Unit.
5
5
33
1
2
3
3
POWER SUPPLY Unit
4
4 4 4
4
Unhook the five hooks.
50FHD X DRIVE Assy
2 -3
1
1
2
Disconnect the four connectors.
Disconnect the three connectors.
Disconnect the 14 screws.
2
3
4
Disconnect the 50FHD X DRIVE ASSY.
5
5
4
4
4
50FHD X DRIVE Assy
x 6
3
x 8x 8

Pioneer PDP-5000EX Specifications

General

Depth	98 mm
Width	1282 mm
Height	750 mm
Weight	39800 g
Pixel pitch	- mm
Product color	Black
Audio (L/R) in	1
Noise reduction	Yes
RMS rated power	13 W
Display diagonal	50 \
Display brightness	1000 cd/m²
Display technology	Plasma
Power requirements	AC 110 - 240 V, 50/60 Hz
Contrast ratio (typical)	3000:1
Power consumption (standby)	0.4 W
Power consumption (typical)	420 W
