Pioneer PDP-5000EX Service Manual

PDP-5000EX
93
5678
56
7
8
C
D
F
A
B
E
Rear Case (F)
2
4
4
4
2 2
1
4
4
4
1
Remove the four screws. (HMB50P140FTB)
2
Remove the 2 grips.
3
Remove the 16 screws.(AMZ30P060FTB)
A -1
one screw. (AMZ30P060FTB)
A -2
one screw. (AMZ30P060FTB)
4
Remove the six screws.(TBZ40P080FTB)
5
5
Remove the rear case (F).
Rear Case (F)
For easy reattachment, be sure to install the screws
for the Rear case in the order indicated in the photo.
After securing those screws in place, the other screws
1
3
3 3
3 3
3 3
3 3
3 3 3
3 3 3
3
A -1
A -2
A -1
A -2
Disassembly (2)
About reattachment

Pioneer PDP-5000EX Specifications

General

Depth	98 mm
Width	1282 mm
Height	750 mm
Weight	39800 g
Pixel pitch	- mm
Product color	Black
Audio (L/R) in	1
Noise reduction	Yes
RMS rated power	13 W
Display diagonal	50 \
Display brightness	1000 cd/m²
Display technology	Plasma
Power requirements	AC 110 - 240 V, 50/60 Hz
Contrast ratio (typical)	3000:1
Power consumption (standby)	0.4 W
Power consumption (typical)	420 W
