l
Minimum: 44.2 x 100 mm
l
Maximum: 44.7 x 200 mm
For a proper seal, the envelope’s minimum flap angle must meet the following criteria:
l
For envelopes with a flap length from 25-60 mm, the minimum flap angle is 18 degrees.
l
For envelopes with a flap length greater than 60 mm to the maximum flap length for the
particular model, the minimum flap angle is 21 degrees.
15 • Product Information
Pitney Bowes User Guide June 2022 114
