Planet Switch User Manual

Industrial Renewable Energy 4-Port 10/100/1000T
802.3at PoE+ Managed Ethernet Switch/Router
BSP-360
62
Object Description
PoE Function
Allows user to disable or enable per port PoE function, and also allows
user to choose schedule by enabling PoE Schedule function of each
port.
Schedule
Indicates the scheduled profile mode. Possible profiles are:
Profile1
Profile2
Profile3
Profile4
This function available when choosing schedule on each port.
button
Saves the current configuration.
button
Refreshes the Web page and the current configuration if user doesn’t
save it.
Auto-Refresh
Check this box to refresh the page automatically. Automatic refresh
occurs every 3 seconds.
Table 4-6-3: Descriptions of the per Port PoE Schedule Profile Objects
PoE Schedule user can configure a duration time for PoE port as default value does not provide power;
screen in Figure 4-6-5 and Table 4-6-4 show.
Figure 4-6-5: PoE Schedule Web Page Screen

Planet Switch Specifications

General

Form Factor	Desktop
Port Speed	10/100/1000 Mbps
MAC Address Table	8K
Switching Capacity	16 Gbps
Operating Temperature	0 to 50°C
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
