Industrial Renewable Energy 4-Port 10/100/1000T
802.3at PoE+ Managed Ethernet Switch/Router
BSP-360
63
Object Description
Profile
Set the schedule profile mode. Possible profiles are:
Profile1
Profile2
Profile3
Profile4
Delete
Check to delete the entry.
Week Day
Allows user to set week day for defining PoE function by enabling it on
the day.
Sun.: Sunday
Mon.: Monday
Tue.: Tuesday
Wed.: Wednesday
Thu.: Thursday
Fri.: Friday
Sat.: Saturday
Start Hour
Allows user to set what hour PoE function does by enabling it.
Start Min
Allows user to set what minute PoE function does by enabling it.
End Hour
Allows user to set what hour PoE function does by disabling it.
End Min
Allows user to set what minute PoE function does by disabling it.
Reboot Enable
Allows user to enable or disable the whole PoE port reboot by PoE
reboot schedule. Please note that if you want PoE schedule and PoE
reboot schedule to work at the same time, please use this function, and
don’t use Reboot Only function. This function offers administrator to
reboot PoE device at an indicated time if administrator has this kind of
requirement.
Reboot Only
Allows user to reboot PoE function by PoE reboot schedule. Please note
that if administrator enables this function, PoE schedule will not set time
to profile. This function is just for PoE port to reset at an indicated time.
Reboot Hour
Allows user to set what hour PoE reboots. This function is only for PoE
reboot schedule.
button
Click to add new rule.
button
Click to apply changes.
button
Check to delete the entry.
Table 4-6-4: Descriptions of the PoE Schedule Configuration Objects
