User Manual of WNAP-6325
-11-
1.4 Product Specification
Product
WNAP-6325
300Mbps 802.11n Wireless Outdoor CPE
Hardware
Standard Support
IEEE802.11b/g/n
IEEE 802.3
IEEE 802.3u
IEEE 802.3x
Chipset
Atheros AR9344
Memory
64 Mbytes DDR SDRAM
16 Mbytes Flash
PoE
Passive PoE
Interface
Wireless IEEE802.11b/g/n, 2T2R
PoE LAN (LAN 1): 1 x 10/100BASE-TX, auto-MDI/MDIX, passive PoE
LAN 2: 1 x 10/100BASE-TX, auto-MDI/MDIX, passive PoE out pass-through
Antenna
Built-in 12dBi Dual-Polarization Antenna
- Horizontal: 30 degrees
- Vertical: 20 degrees
Data Rate
IEEE 802.11b: 1, 2, 5.5, 11Mbps
IEEE 802.11g: up to 54Mbps
IEEE 802.11n (20MHz): up to 150Mbps
IEEE 802.11n (40MHz): up to 300Mbps
Media Access Control
CSMA/CA
Modulation
Transmission/Emission type: OFDM
Data modulation type: OFDM with BPSK, QPSK, 16-QAM, 64-QAM
Frequency Band
2.412GHz ~ 2.484GHz
Operating Channel
America/ FCC: 2.414~2.462GHz (11 Channels)
Europe/ ETSI: 2.412~2.472GHz (13 Channels)
Japan/ TELEC: 2.412~2.484GHz (14 Channels)
RF Output Power (dBm)
IEEE 802.11b: up to 26 ± 1dBm
IEEE 802.11g: up to 23 ± 1dBm
IEEE 802.11n: up to 22 ± 1dBm
Receiver Sensitivity
(dBm)
IEEE 802.11b: -94dBm
IEEE 802.11g: -91dBm
IEEE 802.11n: -89dBm
Output Power Control
12~27Bm
Power Consumption
12W
Power Requirements
LAN 24VDC, 1A/ Passive PoE
Pin 4,5 VDC+
Pin 7,8 VDC-
Pin 3 Reset
Environment & Certification
