User Manual of WNAP-6325
-54-
Object Description
 Filtering
Enable or disable Mac Filtering.
 Mac Address
Enter the Mac address to be filtered.
 Comment
Set a name for the rule.
5.1.19 Bandwidth Control
Click “Operation Mode”  “AP Router” or “Wireless ISP” and then enter the “Bandwidth Control” by clicking
the Setup button next to it. This section allows you to configure the bandwidth control.
Figure 5-31 Bandwidth Control Settings
Object Description
 Quality of
Service
Enable or disable the QoS service.
 Type
Select QoS type IP Address or Mac Address.
 Local IP Address
The IP address segment which uses this QoS rule.
 MAC Address
The Mac address which uses this QoS rule.
 Uplink BandWidth
(Kbps)
Set the maximum uplink bandwidth allowed by the listed QoS rules.
 Downlink
BandWidth (Kbps)
Set the maximum downlink bandwidth allowed by the listed QoS rules.
 Comment
Set a name for the rule.
