User Manual of WNAP-6325
-42-
WMM Capable
BE Traditional IP data, medium throughput and delay.
BK High throughput, non time sensitive bulk data e.g. FTP
VI Time sensitive video data with minimum time delay.
VO Time sensitive data such as VoIP and streaming media with
minimum time delay.
Aifsn Arbitration Inter-Frame Space (milliseconds): Specifies
additional time between when a channel goes idle and the
AP/client sends data frames. Traffic with a lower AIFSN
value has a higher priority.
CWMin Maximum Contention Window (milliseconds): This value is
the upper limit to random backoff value doubling (see
above).
CWMax Arbitration Inter-Frame Space (milliseconds): Specifies
additional time between when a channel goes idle and the
AP/client sends data frames. Traffic with a lower AIFSN
value has a higher priority.
Txop Transmission Opportunity (milliseconds): The maximum
interval of time an AP/client can transmit. This makes
channel access more efficiently prioritized. A value of 0
means only one frame per transmission. A greater value
effects higher priority.
5.1.9 Access Control
Choose the operation mode you require, and then enter “Access Control” by clicking the Setup button next to it
and the following page will be displayed. This section allows you to configure the wireless access control
settings.
