User Manual of WNAP-6325
-43-
Figure 5-19 Access Control
Object Description
Wireless Access
Control Mode
You can choose “Disable”, “Allow Listed” or “Deny Listed”.
Mac Address The MAC address to be filtered.
Comment Enter a comment of this setting.
5.1.10 WAN Port Settings
Click “Operation Mode”  “AP Router” or “Wireless ISP” and then enter the “WAN Port Settings” by clicking
the Setup button next to it. This section allows you to configure the internet connection settings.
 DHCP (Auto Config)
Choose “DHCP” and the router will automatically obtain IP addresses, subnet masks and gateway addresses
from your ISP.
Figure 5-20 WAN Port Settings – DHCP
