User Manual of WNAP-6325
-31-
 Disable SSID Broadcasting
Check it to disable SSID broadcasting.
Enable Isolated
Check it to isolate each connected wireless clients so that they
cannot access each other.
Lock to AP MAC
Enter the Mac address of the remote AP.
Radio Mode
Select the channel width to “Auto Select”, “2G 11NG HT20” or
“2G 11NG HT40”
 Data Rate
Select MCS0~15 or Auto from the pull-down menu. The default
is “Auto”.
 Security Setting
Press “Setup” for more configurations. Please refer to 5.1.7
Security Setting for more information.
 Transmit Power
The range of Transmit power is “12~27 dbm”. In case of
shortening the distance and the coverage of the wireless
network, input a smaller value to reduce the radio transmission
power.
 Transmit Distance
Select a specified distance of the two nodes.
 TDMA
Displays the System Time.
 Advanced Settings
Press “Setup” for more configurations. Please refer to 5.1.8
Advanced Settings for more information.
 Access Control
Press “Setup” for more configurations. Please refer to 5.1.9
Access Control for more information.
5.1.3 WDS AP
Click “Operation Mode”  “WDS AP” and the following page will be displayed. This section allows you to
configure the WDS AP mode. For each wireless parameter, please refer to section 5.1.1 AP for more
information.
