User Manual of WNAP-6325
-44-
Static Mode (Fixed IP)
If your ISP offers you static IP Internet connection type, select “Static Mode" and then enter IP address, subnet
mask, primary DNS and secondary DNS information provided by your ISP in the corresponding fields.
Figure 5-21 WAN Port Settings – Static IP
Object Description
IP Address
Assigned by
Your ISP
Enter the WAN IP address provided by your ISP. Enquire your ISP if you
are not clear.
IP Subnet Mask
Enter WAN Subnet Mask provided by your ISP.
ISP Gateway IP
Address
Enter the WAN Gateway address provided by your ISP.
Primary DNS
Server
Enter the necessary DNS address provided by your ISP. Default is
8.8.4.4.
Secondary DNS
Server
Enter the other DNS address if your ISP provides you with 2 such
addresses. Default is 8.8.8.8.
PPPOE (ADSL)
Select PPPOE if your ISP is using a PPPoE connection and provide you with PPPoE user name and password
info.
