Planmeca Compact i3 Installation Manual

13 Attaching suction tubes and assistant's syringe
Steps
1. Attach the suction tube to the suction tube connector on the underside of
the suction element (1).
2. Secure it into position with the securing ring (2).
3. Attach the assistant's syringe (4) to the quick-connector on the underside
of the suction element (3).
4. Attach the suction tubes and the tube for the assistant's syringe to the
holder on the suction arm.
13 Attaching suction tubes and assistant's syringe
Installation manual Planmeca Compact i3 69
