Adjust the rotational friction of the console arm with the 4 mm Allen key.
Adjust the two screws equally to avoid wearing. Tightening the screws
increases the friction.
Adjust the rotational friction of the instrument console with the 4 mm Allen
key. Adjust the two screws equally to avoid wearing. Tightening the screws
increases the friction.
Adjust the lifting friction of the console arm with the 4 mm Allen key.
Tightening the screw increases the friction.
17 Final adjustments
92 Planmeca Compact i3 Installation manual
