Planmeca PlanScan - Margin Editing Tools

Move Margin tool
Use the Move Margin tool to drag and drop a section of the margin into a new position.
1 Click the Move Margin button.
2 Position the pointer on the margin; click and hold down the mouse button.
Note: Area of Inuence - Change the tool’s area of inuence by dragging the
yellow button to increase or decrease the size of the ellipse.
3 Drag the margin onto the margin shelf and release the mouse button.
The system automatically redraws the margin in the new location.
4 Repeat as needed.
Add Segments tool
Use the Add Segments tool to redraw a portion of the margin.
1 Click the Add Segments button.
2 Start by clicking on a portion of the margin line that is acceptable. Then, click to add new points
across the gap in the line. A line traces where you click. Use multiple clicks to create a curve.
3 Click Add Segments. The system redraws the margin and removes the unacceptable section.
4 Repeat as needed.
Preview Library
Click Preview Library to display a preview of the library tooth on top of the preparation.
The size of the preview tooth is based on the margin. The tooth may appear small on partial
restorations. The preview tooth is positioned according to the Orientation. Click Orientation to
use the library tooth as a guide to change the model’s alignment.
10828200.B Margin Tab 41
