< 0.1
Exposure time
3D Pulsed, effective 1.5 ‐ 36 s as indicated ±10%
Pan (SmartPan) 2.5 – 15.6 s as indicated ±10%
ProCeph 0.1 – 1.6 s as indicated ±10%
SID
3D / Pan (SmartPan) 700 mm
Ceph 1700 mm (66.9 in.)
Magnification
3D 1.40 ‐ 1.71
Pan (SmartPan) 1.40
Ceph 1.13
Duty cycle for height adjustment
25 s ON / 400 s OFF
Line voltage
100 ‐ 220 V~ / 50 ‐ 60 Hz
230 ‐ 240 V~ / 50 Hz
Line current
8 ‐ 17 A
Input power
Stand by 150 VA
Exposure 1800 W
Line harmonics
Cos better than 0.9
Max. permissible apparent impedance of supply
mains
0.5 ohm (100 VAC)
Max. continuous heat dissipation
250 W
Internal fuse(s)
One user replaceable fuse 100 ‐ 220 V~ / 16A FF H 500 V
230 ‐ 240 V~ / 8A FF H 500 V
Type 195100 ELU
External fuse(s)
100 ‐ 220 V ~ / 16A min. - 20A max. T 250 V
230 ‐ 240 V ~ / 10A min. - 20A max. T 250 V
Battery
Lithium battery: 3V, CR2032, Panasonic / Varta
Max. weight
Base unit 165 kg (364 lb)
ProCeph 20 kg (44 lb)
19 Technical specifications
104 Planmeca Viso User's manual
